Makino AML 500 Laser Metal Deposition
Unleash the Power of High-Speed Additive Manufacturing Machine
The Makino AML 500 is a revolutionary 5-axis Additive Manufacturing machine that breaks the mold. Capable of printing, repairing, and coating – all on a single platform – the AML 500 delivers unparalleled versatility and efficiency.
Experience unmatched speed: The AML 500 boasts printing speeds up to 5 times faster than conventional laser metal deposition (LMD) systems. This translates to quicker turnaround times and increased productivity for your business.
Precision engineering, minimal distortion: Thanks to the innovative LMD technology, the AML 500 utilizes a lower heat input process. This minimizes thermal distortion in your parts, ensuring exceptional dimensional accuracy and a flawless finish.
Experience unmatched speed: The AML 500 boasts printing speeds up to 5 times faster than conventional laser metal deposition (LMD) systems. This translates to quicker turnaround times and increased productivity for your business.
Precision engineering, minimal distortion: Thanks to the innovative LMD technology, the AML 500 utilizes a lower heat input process. This minimizes thermal distortion in your parts, ensuring exceptional dimensional accuracy and a flawless finish.
Unleash the potential of heat-sensitive materials: The precise temperature control of the AML 500 allows you to work with a broader range of materials, including those previously thought to be incompatible with 3D printing.
The complete 3D solution: Whether you’re building complex prototypes, repairing worn components, or applying functional coatings, the Makino AML 500 offers the ultimate solution for your high-precision 3D needs.
The complete 3D solution: Whether you’re building complex prototypes, repairing worn components, or applying functional coatings, the Makino AML 500 offers the ultimate solution for your high-precision 3D needs.
Available in: Singapore, Thailand, Malaysia & Vietnam
REQUEST A QUOTE / ENQUIRY FORM
MACHINE SPECIFICATIONS
VIDEO
MACHINE SPECIFICATIONS
| X-Axis | 500 mm |
| Y-Axis | 400 mm |
| Z-Axis | 400 mm |
| B-Axis | ±120° |
| C-Axis | 360° |
| Rapid Traverse | >20 m/min |
| Maximum Workpiece Size | Ø 500 mm x 300 mm High |
| Maximum Payload | 60 kg |
| Laser Power | Up to 4KW |
| Laser Spot Diameter | 1~3.2 mm |
| Nozzle Type | Coaxial |
| Controller | Sinumerik ONE |
| Powder Feeder | 2 or more |
| Powder Flowrate | 3-60 g/min |
